| Place of Origin: | Sichuan, China |
|---|---|
| Brand Name: | JIANGHONG or OEM |
| Certification: | Ce/ISO9001/Tlc |
| Model Number: | GYTC8S |
| Minimum Order Quantity: | 20,000 Meters |
| Price: | Can be negotiable |
| Packaging Details: | Fumigated Wooden Tray |
| Delivery Time: | 5-8Days |
| Supply Ability: | 50000000m Per month |
| Application: | Communication Outdoor | Type: | Single-mode Fiber |
|---|---|---|---|
| Connection Structure: | Fig8 SelfSupporting | Core: | 12-24cores |
| Fiber Model: | G652D Or G657A | Loose Tube Material: | PBT |
| Sheath Material: | HDPE MDPE | Transport Package: | Wooden Drum |
| High Light: | 12F Self Supporting Fiber Optic Cable,24F Self Supporting Fiber Optic Cable,12 core armoured fiber optic cable |
||
GYTC8S Figure-8 Self Supporting Fiber Optic Cable Single Mode 12 24 48 72Cores
DESCRIPTION
This product is to put the optical fiber into a loose tube made of high modulus material, and the loose tube is filled with a waterproof compound. The loose tube is covered with a layer of double-sided plastic-coated steel tape longitudinal package, and a water blocking material is added between the steel tape and the loose tube to ensure the compactness and longitudinal water blocking of the optical cable, and the steel wire strand is integrated into an 8-shaped polyethylene sheath Inside.
FEATURES
The steel wire strand has extremely high tensile strength, which is convenient for self-supporting overhead laying and reduces installation costs;
Double-sided plastic-coated steel belt improves the moisture resistance of optical cable
Central tube structure, small diameter, light weight, easy to lay
APPLICATIONS
Outdoor wiring, suitable for overhead, pipeline laying, long distance, inter-office communication
PERFORMANCE
| Type | Max.Attenuation | Tensile test | Crush test | Min.Bending radius | |||
| 1310nm | 1550nm | Short term | Long term | Short term | Long term | ||
| GYTC8S | 0.36dB/km | 0.22dB/km | 4000N | 1000N | 1000N | 300N | 20D |
Company profile
SICHUAN JIANGHONG CABLE MANUFACTURE CO.,LTD,was founded in 1992,located in Jiangyou,Sichuan P.R.China.
BY 26 years development,company has become a modernized enterprise focus on development,manufacture of different cables for radio and TV network,Video monitoring network,FTTH communication and smart home network.Based on advanced production equipment,the annual capacity has reached up to 5 minllion km/year,factory already got ISO9001:2015 quality management certificate.ISO14001:2015 environmental management certificate and OHSAS18001:2007 occasional healthy and safety management system certificate.
1. Experience:with more than 20 years production experience on cable industry . certified supplier for broadcasting and communication company in China domestic and overseas market .
2. Production line:supply different cables for radio and TV network , Video monitoring network , FTTH communication ad smart home network .
3. Certificate:Factory got ISO9001:2015 quality management certificate. ISO14001:2015 environmental management certificate and OHSAS18001:2007 occupational health and safety management system certificate
4. High-quality material:With strict supplier control and raw-material inspection .make sure the product quality stable and reasonable cost .offer high-quality fiber from well-know fiber company . offer self-inspection and 3rd-party test report.
5. Service:One stop service at customer’s convenience,offer solution based on customer's request .
6. Price:Reasonable cost based on quality guaranteed product .
