| Place of Origin: | Sichuan, China |
|---|---|
| Brand Name: | JIANGHONG or OEM |
| Certification: | ISO,TLC |
| Model Number: | GJXH |
| Minimum Order Quantity: | 20,000 Meters |
| Price: | Can Be Negotiated |
| Packaging Details: | Carton+Fumigated Wooden Tray |
| Delivery Time: | 5-8Days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 50000KM per month |
| Product Name: | 4 Cores Indoor Fiber Optic Cable | Core: | 4 Cores |
|---|---|---|---|
| Application: | Indoor Wiring | Fiber Model: | G657A2 |
| Strength Member: | Phosphate Steel Wire | Sheath Material: | LSZH |
| Package: | Carton+roll | Length: | 2km/roll Or Customized |
| Outer Sheath: | PVC | Color: | Aqua |
| High Light: | 2km indoor outdoor armored fiber,G657A2 indoor outdoor armored fiber,PVC aramid yarn fiber optic cable |
||
Indoor Aramid Yarn FRP Strength 4 Core Fiber Optic Cable
SM 4Cores Indoor Fiber Optic Cable Steel Strength Member Drop cable
Description
Good mechanical and environmental characteristics
Flame retardant characteristics meet the requirements of relevant standards.
The mechanical characteristics meet the requirements of relevant stands
Soft, flexible easy to splice and with big capacity data transmission
SM 4cores indoor Fiber Optic Cable is to place the optical fiber in the center, place two parallel steel wire strength members on both sides, squeeze LSZH sheath into cable.
Features
Good mechanical and flame retardant characteristics;
Small bending radius;
Soft, flexible, easy to splice fiber, and with big capacity data transmission;
Applications
Indoor wiring and end users directly cabling
Performance
|
Type |
Max.Attenuation |
Tensile |
Crush |
Minimum Bending radius |
|||
|
1310nm |
1550nm |
Short term |
Long term |
Short term |
Long term |
||
|
GJXH |
0.36dB/km |
0.25dB/km |
80N |
40N |
1000N |
500N |
40.0×Cable-φ |
Company profile
SICHUAN JIANGHONG CABLE MANUFACTURE CO.,LTD,was founded in 1992,located in Jiangyou,Sichuan P.R.China.
BY 26 years development,company has become a modernized enterprise focus on development,manufacture of different cables for radio and TV network,Video monitoring network,FTTH communication and smart home network.Based on advanced production equipment,the annual capacity has reached up to 5 minllion km/year.
1. Experience:with more than 20 years production experience on cable industry . certified supplier for broadcasting and communication company in China domestic and overseas market .
2. Production line:supply different cables for radio and TV network , Video monitoring network , FTTH communication ad smart home network .
3. Certificate:Factory got ISO9001:2015 quality management certificate. ISO14001:2015 environmental management certificate and OHSAS18001:2007 occupational health and safety management system certificate
4. High-quality material:With strict supplier control and raw-material inspection .make sure the product quality stable and reasonable cost .offer high-quality fiber from well-know fiber company . offer self-inspection and 3rd-party test report.
5. Service:One stop service at customer’s convenience,offer solution based on customer's request .
6. Price:Reasonable cost based on quality guaranteed product .
