| Place of Origin: | Sichuan, China |
|---|---|
| Brand Name: | JIANGHONG or OEM |
| Certification: | ISO9001/Tlc |
| Model Number: | ADSS(Double Jacket) |
| Minimum Order Quantity: | 20,000 Meters |
| Price: | Can be negotiable |
| Packaging Details: | Fumigated Wooden Tray |
| Delivery Time: | 5-8Days |
| Supply Ability: | 50000000m Per month |
| Application: | Communication Cable | Material Shape: | Round Wire |
|---|---|---|---|
| Cable Structure: | Non-metal | Cores: | 24cores |
| Fiber Model: | G652D | Strength Member: | Fiberglass Reinforced Plastic (FRP) |
| Sheath Material: | HDPE MDPE(Double Jacket) | Length: | 3km/Drum |
| Packing: | Fumigated Wooden Tray | ||
| High Light: | 100m Span ADSS Cable,48core ADSS Cable Aramid Yarn,Double Jacket ADSS Fiber Optic Cable |
||
DESCRIPTION
1. ADSS cable is loose tube stranded. Fibers, 250μm , are positioned into a loose tube made of high modulus plastics.
FEATURES
1. Good mechanical and temperature performance.
2. Light weight and small diameter reducing the load caused by ice and wind and the load on towers and backdrops.
3. Aramid yarn as strength making cable have excellent tensile strength performance.4.Large span lengths and the largest span is over 1000m.
APPLICATIONS
Long distance telecom, LAN in high voltage area or access to telecom network;
For power transmission system, much thunder areas and high electro-magnetic inerference.
PERFORMANCE
| Fiber Characteristic | ||
| Attenuation | 1310nm:≤0.35dB/km | |
| 1550nm:≤0.21dB/km | ||
| Cutoff wavelength | When the cut-off wavelength of the optical fiber cable was tested on a 22 m long cable sample, it was less than 1260 nm. | |
| Bending characteristics | The attenuation characteristic test of 1550 nm was carried out after loosening 100 turns from the bending radius of 37.5 mm, and the attenuation increase value did not exceed 0.05 dB. | |
| Mode field diameter | 1550nm : 10.4±0.5μm | |
| 1310nm:9.1±0.4μm | ||
| Cladding diameter | 125±0.7μm | |
| Cladding non-circularity | <1% | |
| Mode length non-circularity | <6% | |
| Coating diameter | 245±10 μm | |
| Macro-bending radius | 100trun X 30mm @1625 nm | ≤0.05dB |
| Mode field/cladding concentricity deviation | ≤10μm | |
| Mechanical and Enviromental test | ||
| Item | Test method | Acceptance Condition |
|
Tensile strength ( IEC60794-1-2-E1) |
Load : 2700N | Loss change ≤ 0.05dB@1550nm No fiber break nor sheath damage |
| Length of cable: about 50m | ||
| Load time : 1 Min | ||
| Crush test | Load : Short term crush(1100 N/cm) | Loss change ≤ 0.05dB@1550nm No fiber break nor sheath damage |
| Load time : 1 Min | ||
| Impact test | Points of impact : 10 | Loss change ≤ 0.05dB@1550nm No fiber break nor sheath damage |
| Times per point : 1 | ||
| Impact energy : 10J | ||
| Repeated bending | Bending dynamic radius : 20 D | Loss change ≤ 0.05dB@1550nm No fiber break nor sheath damage |
| NO. of cycle : 20 | ||
| Torsion | Length:1m | Loss change ≤ 0.05dB@1550nm No fiber break nor sheath damage |
| -Twist angle;±90° | ||
| -No. of cycle:10 | ||
| Water penetration | Height of water : 1m | No water leakage |
| Sample length:3m | ||
| Time :24 h | ||
| Temperature cycling | Temperature :-40~+70ºC | Loss change ≤ 0.05dB@1550nm No fiber break nor sheath damage |
| Time of each step:24h | ||
| No. of cycle :1 | ||
| Drip test | 0~70 degree | No filling compound dripping |
| High pressure test | AC10KV , 50Hz | Loss change ≤ 0.05dB@1550nm No fiber break nor sheath damage |
COMPANY PROFILE
SICHUAN JIANGHONG CABLE MANUFACTURE CO.,LTD,was founded in 1992,located in Jiangyou,Sichuan P.R.China.
BY 26 years development,company has become a modernized enterprise focus on development,manufacture of different cables for radio and TV network,Video monitoring network,FTTH communication and smart home network.Based on advanced production equipment,the annual capacity has reached up to 5 minllion km/year.
1. Experience:with more than 20 years production experience on cable industry . certified supplier for broadcasting and communication company in China domestic and overseas market .
2. Production line:supply different cables for radio and TV network , Video monitoring network , FTTH communication ad smart home network .
3. Certificate:Factory got ISO9001:2015 quality management certificate. ISO14001:2015 environmental management certificate and OHSAS18001:2007 occupational health and safety management system certificate
4. High-quality material:With strict supplier control and raw-material inspection .make sure the product quality stable and reasonable cost .offer high-quality fiber from well-know fiber company . offer self-inspection and 3rd-party test report.
5. Service:One stop service at customer’s convenience,offer solution based on customer's request .
6. Price:Reasonable cost based on quality guaranteed product .
