12 24 48 72 96Cores Armored Steel belt Stranded Outdoor Fiber Optic Cable

Basic Information
Place of Origin: Sichuan, China
Brand Name: JIANGHONG or OEM
Certification: Ce/ISO9001/Tlc
Model Number: GYFTY
Minimum Order Quantity: 20,000 Meters
Price: Can be negotiable
Packaging Details: Fumigated Wooden Tray
Delivery Time: 5-8Days
Supply Ability: 50000000m Per month
Application: CommunicationTelecommunication Type: Single-mode Fiber
Connection Structure: Stranded Loose Tube Core: 24-144cores
Fiber Model: G652D Or G657A Loose Tube Material: PBT
Armored: Steel Belt Sheath Material: HDPE MDPE
Length: 3km/Drum Or Customized Transport Package: Wooden Drum

GYFTY Stranded Outdoor Fiber Optic Cable Single Mode 24 48 72 96 144 256Cores



DESCRIPTION


GYFTY outdoor fiber optic cable is to insert optical fiber into a loose tube made of high modulus material, filled with water-blocking compounds. The center of the cable is FRP, The loose tube and filling rope around the center strengthen the core winch to form a compact and round cable core. The gap in the cable core is filled with water blocking fillings. A layer of polyethylene inner sheath is pressed into the cable core.

FEATURES


Low loss and dispersion of optical fiber transmission
Full cross section water-blocking structure to ensure water-blocking and moisture proof performance
Non-metallic structure with good flexibility and anti-electromagnetic interference performance


APPLICATIONS


Duct and Aerial cabling

PERFORMANCE

Type Max.Attenuation Tensile test  Crush test  Minimum Bending radius
1310nm 1550nm Short term Long term Short term Long term
GYFTY 0.36dB/km 0.22dB/km 1500N 600N 1000N 300N 20D



Company profile



SICHUAN JIANGHONG CABLE MANUFACTURE CO.,LTD,was founded in 1992,located in Jiangyou,Sichuan P.R.China.

BY 26 years development,company has become a modernized enterprise focus on development,manufacture of different cables for radio and TV network,Video monitoring network,FTTH communication and smart home network.Based on advanced production equipment,the annual capacity has reached up to 5 minllion km/year,factory already got ISO9001:2015 quality management certificate.ISO14001:2015 environmental management certificate and OHSAS18001:2007 occasional healthy and safety management system certificate.

1. Experience:with more than 20 years production experience on cable industry . certified supplier for broadcasting and communication company in China domestic and overseas market .
2. Production line:supply different cables for radio and TV network , Video monitoring network , FTTH communication ad smart home network .
3. Certificate:Factory got ISO9001:2015 quality management certificate. ISO14001:2015 environmental management certificate and OHSAS18001:2007 occupational health and safety management system certificate

4. High-quality material:With strict supplier control and raw-material inspection .make sure the product quality stable and reasonable cost .offer high-quality fiber from well-know fiber company . offer self-inspection and 3rd-party test report.
5. Service:One stop service at customer’s convenience,offer solution based on customer's request .
6. Price:Reasonable cost based on quality guaranteed product .
