PE Sheath 3KM Armored Fiber Optic Cable 12 Strand Single Mode Fiber

Basic Information
Place of Origin: Sichuan, China
Brand Name: JIANGHONG or OEM
Certification: Ce/ISO9001/Tlc
Model Number: GYXTA-8
Minimum Order Quantity: 20,000 Meters
Price: Can be negotiable
Packaging Details: Fumigated Wooden Tray
Delivery Time: 5-8Days
Supply Ability: 50000000m Per month
Application: Communication Type: Single-mode Fiber
Connection Structure: Round Wire Core: 12cores
Fiber Model: G652D Loose Tube Material: PBT(high Quality)
Armored: Aluminum Wire And Composite Belt Sheath Material: HDPE MDPE LSZH
Allowed Lateral Pressure: 100(N/100mm)<1000(N/100mm) Allowed Tensile Strength: 1000N<10000N
Length: 3KM/Drum Or Customized
High Light:

PE sheath armored fiber optic cable

,

3KM armored fiber optic cable

,

3KM 12 strand single mode fiber

Central Loose Tube 12 Cores Outdoor Fiber Optic Cable armored aluminum GYXTA



DESCRIPTION


Metal strength member, Central tube type, gelly filled, Polyethylene(PE) sheath, Outer door optical fiber cable for telecommunication


FEATURES
Proper design and precise control of excess length render the cable excellent mechanical and environmental properties;

With small outer diameter, good mechanical properties and excellent resistance ability of lateral pressure;
Gel-filled loose tube for better protection of fiber
12 twisted steel wires to ensure cable tensile strength and anti-gas bullets and rodent performance

Armored with anti-moist corrugated AL tape
Good water resistance performance

APPLICATIONS

Direct-burial or aerial installation and local trunk line.


PERFORMANCE

Type Max.Attenuation Tensile strength Crush resistance Min.Bending radius(Dynamic)
1310nm 1550nm Short term Long term Short term Long term
GYXTA-12 0.36dB/km 0.22dB/km 1500N 600N 1000N 300N 20D



Company profile



SICHUAN JIANGHONG CABLE MANUFACTURE CO.,LTD,was founded in 1992,located in Jiangyou,Sichuan P.R.China.

BY 26 years development,company has become a modernized enterprise focus on development,manufacture of different cables for radio and TV network,Video monitoring network,FTTH communication and smart home network.Based on advanced production equipment,the annual capacity has reached up to 5 minllion km/year,factory already got ISO9001:2015 quality management certificate.ISO14001:2015 environmental management certificate and OHSAS18001:2007 occasional healthy and safety management system certificate.

1. Experience:with more than 20 years production experience on cable industry . certified supplier for broadcasting and communication company in China domestic and overseas market .
2. Production line:supply different cables for radio and TV network , Video monitoring network , FTTH communication ad smart home network .
3. Certificate:Factory got ISO9001:2015 quality management certificate. ISO14001:2015 environmental management certificate and OHSAS18001:2007 occupational health and safety management system certificate

4. High-quality material:With strict supplier control and raw-material inspection .make sure the product quality stable and reasonable cost .offer high-quality fiber from well-know fiber company . offer self-inspection and 3rd-party test report.
5. Service:One stop service at customer’s convenience,offer solution based on customer's request .
6. Price:Reasonable cost based on quality guaranteed product .
