Application: | Communication | Type: | Single-mode Fiber |
---|---|---|---|
Connection Structure: | Round Wire | Core: | 4cores |
Fiber Model: | G652D | Loose Tube Material: | PBT(high Quality) |
Armored: | Steel Wire | Sheath Material: | HDPE |
Allowed Lateral Pressure: | >1000(N/100mm) | Allowed Tensile Strength: | >10000N |
High Light: | GYXTY G652D Outdoor Fiber Optic Cable,4f Outdoor Fiber Optic Cable,central loose tube cable Single mode |
GYXTY 4 Cores Central Loose Tube Outdoor Fiber Optic Cable Armored Steel wire G652D
DESCRIPTION
The structure of GYXTY optical cable is to put 250µm optical fiber into a loose tube made of high modulus material, and the loose tube is filled with a waterproof compound. Loose tubing is added with water blocking material to ensure longitudinal water penetration of the optical cable. After the steel wire is wrapped into a cable, a polyethylene sheath is extruded outside.
FEATURES
1. Fill the loose tube with special grease (gel) to protect the optical fiber critically;
2. Full-section water blocking structure.
3. A layer of wrapped steel wire ensures the tensile strength of the optical cable and has good anti-rat performance;
4. PE sheath has good resistance to ultraviolet radiation and environmental stress cracking resistance;
5. The service life of the product is more than 25 years;
6. Operation temperature: -40 ~ + 70 ºC
APPLICATIONS
Pipeline or overhead
PERFORMANCE
Type | Max.Attenuation | Tensile strength | Crush resistance | Min.Bending radius | |||
1310nm | 1550nm | Short term | Long term | Short term | Long term | ||
GYXTY-4 | 0.36dB/km | 0.22dB/km | 1500N | 600N | 1000N | 300N | 20D |
Company profile
SICHUAN JIANGHONG CABLE MANUFACTURE CO.,LTD,was founded in 1992,located in Jiangyou,Sichuan P.R.China.
BY 26 years development,company has become a modernized enterprise focus on development,manufacture of different cables for radio and TV network,Video monitoring network,FTTH communication and smart home network.Based on advanced production equipment,the annual capacity has reached up to 5 minllion km/year,factory already got ISO9001:2015 quality management certificate.ISO14001:2015 environmental management certificate and OHSAS18001:2007 occasional healthy and safety management system certificate.
1. Experience:with more than 20 years production experience on cable industry . certified supplier for broadcasting and communication company in China domestic and overseas market .
2. Production line:supply different cables for radio and TV network , Video monitoring network , FTTH communication ad smart home network .
3. Certificate:Factory got ISO9001:2015 quality management certificate. ISO14001:2015 environmental management certificate and OHSAS18001:2007 occupational health and safety management system certificate
4. High-quality material:With strict supplier control and raw-material inspection .make sure the product quality stable and reasonable cost .offer high-quality fiber from well-know fiber company . offer self-inspection and 3rd-party test report.
5. Service:One stop service at customer’s convenience,offer solution based on customer's request .
6. Price:Reasonable cost based on quality guaranteed product .
