| Place of Origin: | Sichuan, China |
|---|---|
| Brand Name: | JIANGHONG or OEM |
| Certification: | Ce/ISO9001/Tlc |
| Model Number: | GYXTY-12 |
| Minimum Order Quantity: | 20,000 Meters |
| Price: | Can be negotiable |
| Packaging Details: | Fumigated Wooden Tray |
| Delivery Time: | 5-8Days |
| Supply Ability: | 50000000m Per month |
| Application: | Communication | Type: | Single-mode Fiber |
|---|---|---|---|
| Connection Structure: | Round Wire | Core: | 12cores |
| Fiber Model: | G652D Or G657A | Loose Tube Material: | PBT(high Quality） |
| Armored: | Steel Wire Strength Member | Sheath Material: | HDPE MDPE |
| Allowed Lateral Pressure: | >1000(N/100mm) | Allowed Tensile Strength: | >10000N |
| High Light: | 12F Outdoor Fiber Optic Cable,HDPE G652D Outdoor Fiber Optic Cable,8 core fiber optic cable G657A |
||
12 Cores G652D G657A Outdoor Fiber Optic Cable One PBT Tube Armored Steel Wire
DESCRIPTION
Mentalic Strength member, Central tube type, jelly filled, Polyethylene(PE) sheath, Outer door optical fiber cable for telecommunication.
FEATURES
Uni-tube gel-filled construction for superior fiber protection.
Steel wire armor provide high tensile and crush resistant.
Compact, easy to install.
UV and waterproof design.
APPLICATIONS
Used for aerial outer door telecommunication
Installed in duct, underground conduit or directly buried
PERFORMANCE
| Type | Max.Attenuation | Tensile strength | Crush resistance | Min.Bending radius | |||
| 1310nm | 1550nm | Short term | Long term | Short term | Long term | ||
| GYXTY-12 | 0.36dB/km | 0.22dB/km | 1500N | 600N | 1000N | 300N | 20D |
Company profile
SICHUAN JIANGHONG CABLE MANUFACTURE CO.,LTD,was founded in 1992,located in Jiangyou,Sichuan P.R.China.
BY 26 years development,company has become a modernized enterprise focus on development,manufacture of different cables for radio and TV network,Video monitoring network,FTTH communication and smart home network.Based on advanced production equipment,the annual capacity has reached up to 5 minllion km/year,factory already got ISO9001:2015 quality management certificate.ISO14001:2015 environmental management certificate and OHSAS18001:2007 occasional healthy and safety management system certificate.
1. Experience:with more than 20 years production experience on cable industry . certified supplier for broadcasting and communication company in China domestic and overseas market .
2. Production line:supply different cables for radio and TV network , Video monitoring network , FTTH communication ad smart home network .
3. Certificate:Factory got ISO9001:2015 quality management certificate. ISO14001:2015 environmental management certificate and OHSAS18001:2007 occupational health and safety management system certificate
4. High-quality material:With strict supplier control and raw-material inspection .make sure the product quality stable and reasonable cost .offer high-quality fiber from well-know fiber company . offer self-inspection and 3rd-party test report.
5. Service:One stop service at customer’s convenience,offer solution based on customer's request .
6. Price:Reasonable cost based on quality guaranteed product .
