12cores 7.5mm External Outdoor Ftth Drop Direct Burial Single Mode Fiber Optic Cable

Basic Information
Place of Origin: Sichuan, China
Brand Name: JIANGHONG or OEM
Certification: Ce/ISO9001/Tlc
Model Number: GYXY-12
Minimum Order Quantity: 20,000 Meters
Price: Can be negotiable
Packaging Details: Fumigated Wooden Tray
Delivery Time: 5-8Days
Supply Ability: 50000000m Per month
Application: Communication Outdoor Type: SM Optical Fiber
Core: 12cores Fiber Model: G652D G657A1 G657A2
Loose Tube Material: PBT Tube Strength Member: Galvanized Or Phosphated Steel Wire
Sheath Material: HDPE MDPE LSZH Length: 3KM/Drum Or Customized
High Light:

12cores outdoor ftth drop cable

,

7.5mm outdoor ftth drop cable

,

external fibre optic cable G657A2

2 4 8 12 Cores GYXY Outdoor Fiber Optic Cable Central Loose Tube Steel Strength Member



DESCRIPTION


The fibers, 250μm, are positioned in a loose tube made of a high modulus plastic. The tubes are filled with a water-resistant filling compound. Over the tube, water-blocking material is applied to keep the cable watertight. Two parallel steel wires are placed at the two sides. The cable is completed with a polyethylene (PE) sheath.

FEATURES



1. Good mechanical and temperature performance
2. High strength loose tube that is hydrolysis resistant
3. Special tube filling compound ensure a critical protection of fiber
4. Crush resistance and flexibility
5. Two parallel steel wires ensure tensile strength
6. Small diameter, light weight and friendly installation


PERFORMANCE

Type

Max.Attenuation

Tensile strength

Crush resistance

Min.Bending radius

1310nm

1550nm

Short term

Long term

Short term

Long term

GYXY-12

0.36dB/km

0.22dB/km

1500N

600N

1000N

300N

20D



Fiber count

2~12

Max. Cores in tube

12

Cable diameter(mm)

7.5-7.7

Tensile strength(N)

1500

Crush resistance
(N/100mm)

Long term

300

Short term

1000

Bending radius

Dynamic

20×D

Static

10×D

Storing temperature

-40°C to +70°C

Operating temperature

-40°C to +70°C



COMPANY PROFILE



SICHUAN JIANGHONG CABLE MANUFACTURE CO.,LTD,was founded in 1992,located in Jiangyou,Sichuan P.R.China.

BY 26 years development,company has become a modernized enterprise focus on development,manufacture of different cables for radio and TV network,Video monitoring network,FTTH communication and smart home network.Based on advanced production equipment,the annual capacity has reached up to 5 minllion km/year,factory already got ISO9001:2015 quality management certificate.ISO14001:2015 environmental management certificate and OHSAS18001:2007 occasional healthy and safety management system certificate.

1. Experience:with more than 20 years production experience on cable industry . certified supplier for broadcasting and communication company in China domestic and overseas market .
2. Production line:supply different cables for radio and TV network , Video monitoring network , FTTH communication ad smart home network .
3. Certificate:Factory got ISO9001:2015 quality management certificate. ISO14001:2015 environmental management certificate and OHSAS18001:2007 occupational health and safety management system certificate

4. High-quality material:With strict supplier control and raw-material inspection .make sure the product quality stable and reasonable cost .offer high-quality fiber from well-know fiber company . offer self-inspection and 3rd-party test report.
5. Service:One stop service at customer’s convenience,offer solution based on customer's request .
6. Price:Reasonable cost based on quality guaranteed product .

12cores 7.5mm External Outdoor Ftth Drop Direct Burial Single Mode Fiber Optic Cable 0

12cores 7.5mm External Outdoor Ftth Drop Direct Burial Single Mode Fiber Optic Cable 1
12cores 7.5mm External Outdoor Ftth Drop Direct Burial Single Mode Fiber Optic Cable 2
12cores 7.5mm External Outdoor Ftth Drop Direct Burial Single Mode Fiber Optic Cable 3
12cores 7.5mm External Outdoor Ftth Drop Direct Burial Single Mode Fiber Optic Cable 4
