72f Armored Outdoor Fiber Optic Cable GYTY53 Directly Buried Single Mode Fiber Double PE

Basic Information
Place of Origin: Sichuan, China
Brand Name: JIANGHONG or OEM
Certification: Ce/ISO9001/Tlc
Model Number: GYTY53-72
Minimum Order Quantity: 20,000 Meters
Price: Can be negotiable
Packaging Details: Fumigated Wooden Tray
Delivery Time: 5-8Days
Supply Ability: 50000000m Per month
Application: Telecommunication Type: Single Mode Fiber
Connection Structure: Stranded Loose Tube Core: 72cores
Fiber Model: G652D Or G657A Loose Tube Material: PBT(high Quality)
Armored: Phosphating Steel Belt Sheath Material: HDPE MDPE(Double Jacket)
Length: 2-4km/Drum Or Customized Transport Package: Wooden Reel
High Light:

72F Outdoor Fiber Optic Cable

,

Armored Outdoor Fiber Optic Cable GYTY53

,

direct burial single mode fiber

72 Cores Armored Outdoor Fiber Optic Cable GYTY53 Anti-Rodent Directly Buried



DESCRIPTION



GYTY53 Outdoor Armored Optical Fiber Cable double PE coated

The fibers are positioned in a loose tube made of a high modulus plastic.The tubes are filled with a water-resistant filling compound.A steel wire,sometimes sheathed with polyethylene(PE) for cable with high fiber count,locates in the center of core as metallic strength member.Tubes(and fillers) are stranded around the strength member into a compact and circular cable core.An Aluminum Polyethylene Laminate(APL) is applied around the cable core,which is filled with the filling compound to protect it from water ingress.Then the cable core is covered with a thin PE inner sheath.After the PSP is longitudinally applied over the inner sheath,the cable is completed with a PE sheath.


FEATURES



1. Good mechanical and temperature performance.
2. Heigh strength loose tube that is hydrolysis resistand
3. Specially tube filling compound ensure a critical protection of fiber
4. Specially designed compact structure is good at preventing loose tubes from shrinking
5. PE sheath protects cable form ultraviolet radiation
6. Steel wire used as the central strength member
7.100% cable filling core filling
6. Loose tubs filling compound
7. Corrugated Steel Tape enhancing mostiure-proof
8. Water-blocking material



APPLICATIONS


Buried, aerial
Relay communication system
Core network, metropolitan area network and access network, etc


PERFORMANCE

Type Max.Attenuation Tensile test  Crush test  Min.Bending radius
1310nm 1550nm Short term Long term Short term Long term
GYTY53-72 0.36dB/km 0.22dB/km 4000N 2000N 3000N 1000N 25D



Company profile



SICHUAN JIANGHONG CABLE MANUFACTURE CO.,LTD,was founded in 1992,located in Jiangyou,Sichuan P.R.China.

BY 26 years development,company has become a modernized enterprise focus on development,manufacture of different cables for radio and TV network,Video monitoring network,FTTH communication and smart home network.Based on advanced production equipment,the annual capacity has reached up to 5 minllion km/year,factory already got ISO9001:2015 quality management certificate.ISO14001:2015 environmental management certificate and OHSAS18001:2007 occasional healthy and safety management system certificate.

1. Experience:with more than 20 years production experience on cable industry . certified supplier for broadcasting and communication company in China domestic and overseas market .
2. Production line:supply different cables for radio and TV network , Video monitoring network , FTTH communication ad smart home network .
3. Certificate:Factory got ISO9001:2015 quality management certificate. ISO14001:2015 environmental management certificate and OHSAS18001:2007 occupational health and safety management system certificate

4. High-quality material:With strict supplier control and raw-material inspection .make sure the product quality stable and reasonable cost .offer high-quality fiber from well-know fiber company . offer self-inspection and 3rd-party test report.
5. Service:One stop service at customer’s convenience,offer solution based on customer's request .
6. Price:Reasonable cost based on quality guaranteed product .

72f Armored Outdoor Fiber Optic Cable GYTY53 Directly Buried  Single Mode Fiber Double PE 0

72f Armored Outdoor Fiber Optic Cable GYTY53 Directly Buried  Single Mode Fiber Double PE 1
72f Armored Outdoor Fiber Optic Cable GYTY53 Directly Buried  Single Mode Fiber Double PE 2
72f Armored Outdoor Fiber Optic Cable GYTY53 Directly Buried  Single Mode Fiber Double PE 3
72f Armored Outdoor Fiber Optic Cable GYTY53 Directly Buried  Single Mode Fiber Double PE 4
