12 Cores G652D Figure 8 Aerial Cable All Dielectric Self Supporting GYXTC8S Central Tube

Basic Information
Place of Origin: Sichuan, China
Brand Name: JIANGHONG or OEM
Certification: Ce/ISO9001/Tlc
Model Number: GYTC8S-12
Minimum Order Quantity: 20,000 Meters
Price: Can be negotiable
Packaging Details: Fumigated Wooden Tray
Delivery Time: 5-8Days
Supply Ability: 50000000m Per month
Application: Communication And FTTH Type: SM Optical Fiber
Connection Structure: Fig8 Self-Supporting Central Tube Core: 8cores
Fiber Model: G652D Or G657A Loose Tube Material: PBT Tube
Sheath Material: HDPE MDPE LSZH Transport Package: Wooden Reel Or Customized
High Light:

12 Cores figure 8 aerial cable

,

G652D figure 8 aerial cable

,

all dielectric self supporting MDPE sheath

12 Cores G652D Figure-8 Self Supporting Fiber Optic Cable GYXTC8S Central Tube



DESCRIPTION

Fiber Optic Cable,GYXTC8S,The structure of the cable (self-supporting loose-bubed stranded padding outdoor communication cable with metallic strengthened hanging line andsteel-PE cementing sheath) is covering the inner-fulfilled waterproof compound loose tube, which is made of high modulus plastic, with the single mode andmulti-mode optical fiber.There is a FFRP in the middle of the optical cablecore. The compact and round shape cable core is a combination of the loose sleeve pipe(gasket for packing ) and center-strengthened core, the gap in thecable core is filled with water retarding compound. PE sheath will be cable dafter the metal strengthened hanging line is parellely installed with the cablecore, which is longitudinally covered with plastic-plastic-plated steel tape.

FEATURES


It controls the extra length of the optical fiber precisely to ensure the good performance of stretch-proof and environmental characteristic of the optical cable.
The double side plastic-plated steel tape provides an excellent of moisture proofand side compression resistance.
The Zn-plated steel stranded wire ensures the anti-stretch intensity, which isrequired by the self-supporting cable installation.
The cable is application the self-supporting aerial wiring with the span of 100m orbelow. It provides a more efficient construction, and saves the hanging linesand cable drop hangers at the same time.


APPLICATIONS
The product is applicable for long-distance and interoffice communication.


PERFORMANCE

Type Max.Attenuation Tensile test  Crush test  Min.Bending radius
1310nm 1550nm Short term Long term Short term Long term
GYTC8S-8 0.36dB/km 0.22dB/km 4000N 1000N 1000N 300N 20D



Company profile



SICHUAN JIANGHONG CABLE MANUFACTURE CO.,LTD,was founded in 1992,located in Jiangyou,Sichuan P.R.China.

BY 26 years development,company has become a modernized enterprise focus on development,manufacture of different cables for radio and TV network,Video monitoring network,FTTH communication and smart home network.Based on advanced production equipment,the annual capacity has reached up to 5 minllion km/year,factory already got ISO9001:2015 quality management certificate.ISO14001:2015 environmental management certificate and OHSAS18001:2007 occasional healthy and safety management system certificate.

1. Experience:with more than 20 years production experience on cable industry . certified supplier for broadcasting and communication company in China domestic and overseas market .
2. Production line:supply different cables for radio and TV network , Video monitoring network , FTTH communication ad smart home network .
3. Certificate:Factory got ISO9001:2015 quality management certificate. ISO14001:2015 environmental management certificate and OHSAS18001:2007 occupational health and safety management system certificate

4. High-quality material:With strict supplier control and raw-material inspection .make sure the product quality stable and reasonable cost .offer high-quality fiber from well-know fiber company . offer self-inspection and 3rd-party test report.
5. Service:One stop service at customer’s convenience,offer solution based on customer's request .
6. Price:Reasonable cost based on quality guaranteed product .

12 Cores G652D Figure 8 Aerial Cable All Dielectric Self Supporting GYXTC8S Central Tube 0

12 Cores G652D Figure 8 Aerial Cable All Dielectric Self Supporting GYXTC8S Central Tube 1
12 Cores G652D Figure 8 Aerial Cable All Dielectric Self Supporting GYXTC8S Central Tube 2
12 Cores G652D Figure 8 Aerial Cable All Dielectric Self Supporting GYXTC8S Central Tube 3
12 Cores G652D Figure 8 Aerial Cable All Dielectric Self Supporting GYXTC8S Central Tube 4
